NEC MD211G5 LED display 54,1 cm (21.3") 2048 x 2560 pixels Noir
EAN : 5028695109780
Référence : 3240606
NEC MD211G5 - Écran LED - 5MP - niveaux de gris - 21.3 - 2048 x 2560 - IPS - 1200 cd/m2 - 1200:1 - 25 ms - DVI-D, DisplayPort - noir
6 999,00 €
HT
6 999,00 € TTC
21" 5MP medical diagnostic display (FDA pending)
The 21.3” NEC MultiSync MD11G5 an LED-backlit medical-grade widescreen diagnostic display, is designed for the demanding needs of healthcare professionals in medical imaging and PACS. This 5-megapixel model has an IPS panel to provide precise grayscale reproduction and wide viewing angles, as well as integrated backlight and front sensors, which constantly monitor and adjust brightness to maintain the factory DICOM GSDF calibration. The MD211G5 includes a has four-way ergonomic stand, including height-adjust, swivel, tilt and pivot. The display offers both DisplayPort and DVI-D inputs, built-in two-port USB hub, and 11.9-bit lookup tables (LUTs) with 1024 levels of gray for smooth images and hardware calibration.
- Superior screen performance (1200:1 contrast ratio, 2048 x 2560 native resolution, 1200 cd/m², 500 cd/m² calibratedbrightness)
- Out-of-the-box calibration to the DICOM grayscale display function for luminance
- Uniformity control provides accurate imaging across the screen
- Integrated two-port USB 2.0 hub easily connects you to your peripherals
- Includes GammaCompMD™ QA software for worry-free calibration and conformance testing to the DICOM standard
The 21.3” NEC MultiSync MD11G5 an LED-backlit medical-grade widescreen diagnostic display, is designed for the demanding needs of healthcare professionals in medical imaging and PACS. This 5-megapixel model has an IPS panel to provide precise grayscale reproduction and wide viewing angles, as well as integrated backlight and front sensors, which constantly monitor and adjust brightness to maintain the factory DICOM GSDF calibration. The MD211G5 includes a has four-way ergonomic stand, including height-adjust, swivel, tilt and pivot. The display offers both DisplayPort and DVI-D inputs, built-in two-port USB hub, and 11.9-bit lookup tables (LUTs) with 1024 levels of gray for smooth images and hardware calibration.
- Superior screen performance (1200:1 contrast ratio, 2048 x 2560 native resolution, 1200 cd/m², 500 cd/m² calibratedbrightness)
- Out-of-the-box calibration to the DICOM grayscale display function for luminance
- Uniformity control provides accurate imaging across the screen
- Integrated two-port USB 2.0 hub easily connects you to your peripherals
- Includes GammaCompMD™ QA software for worry-free calibration and conformance testing to the DICOM standard
-
Secteur d'entrée d'alimentationOui
-
Temps de réponse25 ms
-
Entrée audioNon
-
Pas de pixel0,27 x 0,27 cm
-
Poids (avec support)11,8 kg
-
Profondeur (support inclus)227,6 cm
-
Fréquence de balayage vertical25 - 75 Hz
-
Résolutions graphiques prises en charge2560 x 2048
-
Fréquence numérique horizontale30 - 135 kHz
-
Largeur appareil (support inclus)474,5 cm
-
Hauteur (support inclus)541,8 cm
-
Consommation électrique80 W
-
CertificationC-UL, EN 60601-1, ISO 9241-307, ISO 13406-2, US Mercury Regulations, WEEE, RoHS, AAPM-TG18, DIN V 6868-57, FDA 501(k)
-
HDCPNon
-
WifiNon
-
BluetoothNon
-
Bouton marche/arrêt intégréOui
-
VoyantsOui
-
Ajustement de l'inclinaisonOui
-
Poids (sans support)8,6 kg
-
Hauteur (sans support)390 cm
-
Profondeur (sans support)98,2 cm
-
Largeur (sans support)474,5 cm
-
Cartes mémoire compatiblesNon pris en charge
-
Quantité d'interface DisplayPorts1
-
Quantité de ports DVI-D1
-
Consommation d'énergie (mode veille)7 W
-
Sortie audioNon
-
Taux d'humidité relative (stockage)10 - 85%
-
Taux d'humidité de fonctionnement30 - 80%
-
Température hors fonctionnement-20 - 60 °C
-
Altitude de non fonctionnement0 - 10000 m
-
PivotOui
-
Altitude de fonctionnement0 - 3000 m
-
Température d'opération5 - 35 °C
-
Appareil photo intégréNon
-
Port de câble antivolNon
-
Réglage de la hauteurOui
-
Synthoniseur TV intégréNon
-
Câbles inclusSecteur, DisplayPort, DVI, USB
-
Lecteur de cartes mémoires intégréNon
-
Haut-parleurs intégrésNon
-
ÉcranLCD
-
CouleurNoir
-
Domaine de numérisation horizontale30 - 135 kHz
-
position de marchéMedical
-
Compatibilité 3DNon
-
Norme VESA100 x 100 cm
-
Installation prise en chargehorizontale/verticale
-
Montage VESAOui
-
PivotantOui
-
Angle de vision vertical176°
-
Angle de vision horizontal176°
-
Taux de contraste1200:1
-
Format d'image5:4
5:4 -
Écran tactileNon
-
Résolution de l'écran2048 x 2560 pixels
-
Taille de l'écran54,1 cm (21.3")
-
Ethernet/LANNo
Non
